Sports Mesh Fencing

Urban Sports Mesh Fencing (MUGA)

Low maintenance, cost effective MUGA fencing

Urban Sports Fencing is manufactured using 2 types of mesh and aperture

  • Cat 1: Purposely designed to allow for a general purpose medium/high usage sports fencing applications
  • Cat 2: Featuring a complete built in rebound system inserted at the lower 1.2m high section of the panel making this the ideal choice for a complete range of games fencing.

Using 8mm & 6mm wires the Urban Sports Range out performs many of the earlier designs like timber boards, light mesh & chain link, making this a low maintenance product and a truly cost effective solution.



Benefits

  • Flush Safety Edges
  • Designed for high usage
  • Excellent & rigid rebound system
  • Low maintenance
  • Good visibility for spectators
  • No cross rails needed
  • Easy to install

Specifications

  • Heights: 2.4m, 3.0m, 3.2m, 4.0m, 5.0m
  • Mesh Aperture: 200mm x 50mm (Cat 1)
  • (Cat 2)Built in 1.2m Rebound section 50mm x 66.6mm
  • Special panels 200mm x 100mm for top section only
  • Horizontal Wires: 8mm x 2 @ 200mm Centres
  • Vertical Wires: 6mm @ 50mm or 66.6mm (Rebound only)
  • Post Centres: 2500mm

Typical Applications

  • General games areas
  • Basket Ball Courts
  • Football Pitches
  • Hockey
  • Urban Sports Areas
  • MUGA Courts
